1939-1947 Farmall A & AV Tractor Owners/Operators Manual the Owners Manual is the same exact manual received when the tractor was new, it covers all aspects of your tractor.Some of the subjects covered are Maintenance Procedures, Lubrication, Special Attachments, Specifications & Operating your Tractor.

* INSTANT DOWNLOAD NO WAITING
* PDF FORMAT

---------------------------------------------------------------------------
Farmall A Specifications

Model history
Model introduced 1939
Model discontinued 1947
Model status Discontinued
No. produced 128,246 (includes Farmall A-AV, International A)
Preceded by McCormick-Deering Farmall F-14
Superseded by McCormick Farmall Super A

Engine Specification
Engine make International
Engine model C-113
Fuel type distillate
Power hp 16 belt, 15 drawbar
Governed rpm 1400
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3 in
Stroke in (mm) 4 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 4
Reverse 1
Drive 2-WD

General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 4.00-15 4-ply
Rear 9-24 4-ply (8-24 standard)
Tractor Dimensions
Length (inches/metres) 106 in
Width (inches/meters) 56 in
Height (inches/meters) 63 in
Weight (nominal) lb/kg 1780 lb
Turning circle (nominal) inches/meters 18 ft
Wheelbase 71 in

More info
Factories Tractor Works, Chicago, Illinois
Plow rating 1-14"
Nebraska Tests No. 330
Approximate Cost new in (year) $542 (1941), $1295 (1947)

-------------------------------------------------------------------------------------------
Farmall AV Tractor Specs

Model history
Model introduced 1941
Model discontinued 1947
Model status Discontinued
Preceded by New model
Superseded by McCormick Farmall Super AV

Engine Specifications
Engine make International
Engine model C-113
Fuel type gasoline
Power hp 18 belt, 16 drawbar
Governed rpm 1400
Displacement cu in /(litre) 113 ci
No. of Cylinders 4
Bore in (mm) 3 in
Stroke in (mm) 4 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA

Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 4
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 4.00-19 4-ply
Rear 8-36 4-ply
Tractor Dimensions
Length (inches/metres) 115 in
Width (inches/meters) 63 in
Height (inches/meters) 69 in
Weight (nominal) lb/kg 2280 lb
Turning circle (nominal) inches/meters 17.5 ft
Wheelbase 72 in

More info
Factories Tractor Works, Chicago, Illinois
Plow rating 1-16"
Nebraska Tests No. 329 (Farmall A)
Approximate Cost new in (year) $660 (1941)
