LYCOMING O-340 Series Aircraft Engines Parts Catalog IPC IPL Manual PC-105 - DOWNLOAD
- Add To Basket
Instant Download from planeoldmanuals, digital version
This manual is clear and written in a way so that just about anybody can follow it
Navigation is simple with convenient chapter bookmarks and ability to search by keyword. Print out entire manual or just what you'll be working on!
* INSTANT DOWNLOAD NO WAITING
* PDF FORMAT
* LANGUAGE: English
* FORMAT: PDF
* COMPATIBLE: Win/ Mac
* BOOKMARKED - INDEXED - SEARCHABLE
The parts lists and illustrations in this catalog provide an easy method of identification, for procurement and servicing purposes, of any part used on Lycoming Model 0-340 Series Aircraft Engines. The catalog contains six sections which are described in the following paragraphs.
THE ILLUSTRATED PARTS SECTION consists of exploded views of the basic 0-340 Series engines. These views illustrate all procurable parts which are indicated and identified by part number.
THE NUMERICAL PARTS SECTION contains the part number of all procurable parts used on these engines and are arranged in numerical sequence. Following each part listing a complete dimensional description is given along with the quantity required for each engine. If the part is an assembly the quantity, part number and name of its components are given. Certain components of these assemblies may be prefixed by an which indicates that the detail part cannot be procured as such but can be obtained only by ordering the next higher assembly of which it is a component.
THE NUMERICAL STANDARDS PARTS SECTION is similar to the Numerical Parts Section excepting only that the part numbers are prefixed by the symbol "STD". This symbol indicates that the part is a Lycoming standard part and is not necessarily peculiar to these engines. The standard parts include such items as nuts, bolts, washers, and seals.
THE OVERSIZE AND UNDERSIZE PARTS SECTION consists of a list of such parts that are available in sizes other than nominal or standard. This list states the part name or number of the part and the non standard sizes in which it may be procured.
THE SERVICE REPLACEMENT SET SECTION consists of a list of service replacement sets such as seals, gaskets or complete cylinder, piston and ring combinations. The individual items in these sets are listed separately in the Numerical Section of the catalog and may be individually procured.
THE ATTACHING PARTS SECTION consists of a complete listing of all assemblies and subassemblies contained in the engine, along with their attaching parts. These assemblies and subassemblies are arranged in an alphabetical sequence and immediately beneath each listing are shown the parts that are required to attach each assembly. The quantity shown under the "No. Required" column are for one assembly only.
Excellent item for your Repair Reference Library!
Why pay big bucks to have someone else print it for you?
Print what you need when you need it.
We have thousands of Airplane & Engine Manuals - Please email us about any you might need!
Tags: LYCOMING 0-340 Aircraft pdf 0-340 Airplane Engine Engines illustrated Part Parts Catalog Catalogs Service Manual Manuals IPL IPC Instant Download Immediate downloads PC-105 pc105 free pdf book ebook
