Canon GP216, 215, 211, 210, 200 Parts Manual.


After purchasing a new item, sometimes the product manuals can get caught up in the packaging and discarded or over time can get mislaid. Most of us think, I would never open up the product to find out what is wrong, so what do I really need my manual for? The assumption that your product manual is only for people with great technical skill is a misconception. Purchasing a parts manual for your copier can save time, money and aggravation.

The parts manual provides exploded diagrams with references to part numbers.
Contains 365 pages in pdf format of all the information you require to maintain your photocopier.
Print off one page or the whole manual.

Contents:-

EXTERNAL COVERS, PANELS, ETC.
MACHINE FRONT PLATE
INTERNAL COMPONENTS 1
INTERNAL COMPONENTS 2
MACHINE REAR PLATE
POWER CORD TERMINAL ASSEMBLY (100/120V EXCEPT NJS)
POWER CORD TERMINAL ASSEMBLY (120V NJS/220/240V)
RIGHT DOOR ASSEMBLY
CONTROL PANEL ASSEMBLY
COPYBOARD COVER ASSEMBLY
COUNTER ASSEMBLY
EXHAUST FAN ASSEMBLY
LASER COOLING FAN ASSEMBLY
LENS MOUNT ASSEMBLY
. MAIN DRIVE ASSEMBLY
FIXING DRIVE ASSEMBLY
CASSETTE
PAPER PICK-UP ASSEMBLY
MULTI FEEDER TRAY ASSEMBLY
FEEDER ASSEMBLY
LOWER PAPER FEEDER ASSEMBLY
LOWER FEED INLET FAN ASSEMBLY
LOWER FEED INLET ASSEMBLY (EXCEPT GP210/210F/211/211F)
REGIST. FRONT GUIDE ASSEMBLY
DELIVERY ASSEMBLY (EXCEPT GP210/210F/211/211F 100V)
DELIVERY ASSEMBLY (GP210/210F/211/211F 100V)
MIRROR ASSEMBLY 1
MIRROR ASSEMBLY 2
SCANNER ASSEMBLY
DRUM CARTRIDGE
DEVELOPING ASSEMBLY
FIXING ASSEMBLY
PCB LOCATION DIAGRAM
DC POWER SUPPLY PCB ASSEMBLY
CONTROL PANEL CPU PCB ASSEMBLY
DC CONTROLLER PCB ASSEMBLY
PAPER PICK-UP PCB ASSEMBLY
IMAGE PROCESSOR PCB ASSEMBLY
MULTI PDL PRINTER BOARD PCB ASSEMBLY
(GP200E NJY/200F)
LIPS PRINTER BOARD PCB ASSEMBLY
(GP215P/216FP)
CORE IMAGE PROCESSOR PCB ASSEMBLY
FAX ASSEMBLY (GP215F/210F/200E/200F)
FAX BOARD PCB ASSEMBLY
(GP215F/210F/200F/200E)
NCU BOARD PCB ASSEMBLY
(GP215F/210F/200E/200F)
MULTI PDL PRINTER BOARD UNIT
(GP200E NJY/200F)
LIPS PRINTER BOARD UNIT (GP215P/216FP)
BOARD CASE ASSEMBLY (GP215/211/210)
