Automated PDF to Text preview page 4 to 6:
4 FDL-PT222 SECTION 2 DISASSEMBLY 2-1. CABINETS 1. Remove the battery cover 8. 2. Push two claws with a screwdriver or equivalent on the bottom and remove them. 1 front cabinet 2 channel button 3 B board claw 3. While pushing the rear cabinet, remove claws of joints with the front cabinet. 4. Insert a screwdriver or equivalent to the gap on the upper side of the cabinet, and while pushing the lock spring, put it down to the rear cabinet side. 6 screw (+PTP2X6) 5. Remove the channel button 2. 6. Disconnect CN501 (for speaker) on the A board. 7. Remove the B board 3 and the A board 4. 8. Remove solder for the lead wire (BLK) 9. 9. Remove a screw (+PTP2X6) 6 secured the T board 5. 10. Release the T1 board 5 from two claws (right and left) on the rear cabinet. 9 lead wire (BLK) claw front cabinet rear cabinet 4 A board 5 T1 board 7 rear cabinet lock spring 8 battery cover 5 FDL-PT222 2-2. SERVICE POSITION Cable for service 1-900-211-84 CN602 CN601 A board Cable for service 1-900-211-84 B board CN301 T1 board CN201 J101 Mini-jack AC power adaptor Antenna 6 |
