DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935 SECTION 1 DISASSEMBLY
· This set can be disassembled in the order shown below.

1-1.

DISASSEMBLY FLOW

SET

2-2. BOTTOM BLOCK (Page 2-1)

2-4. MONITOR SUB ASSY (Page 2-2)

2-2. MAIN BOARD (Page 2-2)

2-5. LCD (Page 2-3)

Note: Follow the disassembly procedure in the numerical order given.

1-2.

BOTTOM BLOCK

2 screw (TS2 × 8.5) 1 foot rubber

5 LCD harness

6 bottom block

2 screw (TS2 × 8.5) 1 foot rubber 1 foot rubber 2 three screws (TS2 × 8.5) 4 four screws (TS2.5 × 11) 3 open preve sheet 1 foot rubber

2 four screws (TS2 × 8.5) 2 four screws (TS2 × 8.5)

1-1

DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935

1-3.

MAIN BOARD

5 travers unit 4 flexible board 3 FFC 2 connector 1 tape 7 main board

6 three screws (TS2 × 4.5)

1-4.

MONITOR SUB ASSY

6 housing cover assy

9 monitor sub assy 4 two screws (TS1.7 × 7) 1 two panel rubbers UPP 5 four screws (TS1.7 × 7)

3 two panel rubbers DOW 2 two panel rubbers ARC

7 four screws (TS2.5 × 6.5)

8 two connectors

1-2

DVP-FX921/FX921K/FX930/FX930CC/FX930WM/FX935

1-5.

LCD

qd panel brac L

qs two screws (TS1.7 × 5)

2 LCD connector

8 screw (TS1.7 × 5)

9 panel brac L-L

4 six screws (TS1.7 × 5)

3 10 pin FFC

5 LCD board 6 screw (TS1.7 × 5) 7 panel brac L-R 0 two screws (TS1.7 × 5) qa panel brac L qf LCD 1 LCD flexible board

1-6.

CIRCUIT BOARDS LOCATION

KEY board

LCD board

MAIN board

1-3E
