SPECIFICATIONS
*^ Mode---------SP mode unless otherwise specified * Test input terminal <Except Tuner>--------Video input (1 Vp-p) Audio input (-10 dB) <Tuner>------------------Ant. input (80 dBµV) Video: 87.5% Audio: 25 kHz dev. (1 kHz Sin)

< DEFLECTION >
Description 1. Over Scan 2. Linearity 3. High Voltage Condition --Horizontal Vertical --Unit % % % kV Nominal 90 ----27 Limit 5 ±18 ±10 ---

< VIDEO & CHROMA >
Description Condition Center 1. Misconvergence Corner Side 2. Tint Control Range 3. Contrast Control Range 4. Brightness (100% White Full Field) 5. Color Temperature ----Contrast: Max --Unit m/m m/m m/m deg dB ft-L K Nominal ------±30 6 40 9200 Limit 0.4 2.5 1.5 --2 24 ---

< DVD >
Description 1. Horizontal Resolution (TDV-540 TIT.2 CHP.16) 2. Video S/N at CN3400 (TDV-540 TIT.2 CHP.6) 3. S/N Chroma at CN3400 (TDV-540 TIT.2 CHP.17) AM PM Condition --------L R L, 20 Hz R, 20 Hz L, 20 kHz R, 20 kHz L R Unit Line dB dB dB % Nominal 350 60 58 58 0.03 Limit 330 55 53 53 0.07

4. Audio Distortion (LPCM 48 kHz, W/LPF) (PTD 1-NOR TIT.1 CHP.1) 5. Audio freq. response (LPCM 48 kHz) (PTD 1-NOR TIT.1 CHP.5 -- 10) 6. Audio S/N (LPCM 48 kHz,W/LPF,A-WTD) (PTD 1-NOR TIT.1 CHP.1 -- 2)

dB

0

+4/-5

dB

85

75

1-1-1

T1100SP

< VCR >
Description 1. Horizontal Resolution 2. Jitter (Low) 3. S/N Chroma AM(SP) PM(SP) Condition (R/P, SP) (R/P, SP) (R/P, SP) (R/P, SP) (R/P, SP) Unit Line µs dB dB % Nominal 230 0.1 38 38 0.25 Limit 200 0.2 33 33 0.5

4. Wow & Flutter (JIS, UNWTD)

< TUNER >
Description 1. Video S/N (80 dBµV, TV4ch) 2. Audio S/N (W/LPF) Condition ----Unit dB dB Nominal 45 45 Limit 40 40

< NORMAL AUDIO>
All items are measured across 8 resistor at speaker output terminal. Description 1. Audio Output Power 2. Audio S/N (W/LPF) 3. Audio distortion (W/LPF, -10 dB 1 kHz IN) 4. Audio Freq. Response (-10dB 1kHz IN) 200 Hz 8 kHz Condition (R/P, SP) (R/P, SP) (R/P, SP) (R/P, SP) (R/P, SP) Unit W dB % dB dB Nominal 1.0 40 3.0 -2.0 0 Limit 0.8 36 5.0 -2.0±5.0 0±6.0

< Hi-Fi AUDIO >
Description 1. Output Level (-10 dB 1 kHz IN) 2. Audio Distortion (-10 dB 1 kHz IN) 3. Freq. Response (-15 dB 1 kHz IN) 20 Hz 20 kHz Condition (R/P, SP) (R/P, SP) (R/P, SP) (R/P, SP) Unit dB % dB dB Nominal -8.0 0.5 0 0 Limit -8±4 1.0 ±4 ±4

Note: Nominal specifications represent the design specifications. All units should be able to approximate these. Some will exceed and some may drop slightly below these specifications. Limit specifications represent the absolute worst condition that still might be considered acceptable. In no case should a unit fail to meet limit specifications.

1-1-2

T1100SP

LASER BEAM SAFETY PRECAUTIONS
This DVD player uses a pickup that emits a laser beam.

Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin.

The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30 cm away from the pickup lens when the diode is turned on. Do not look directly at the laser beam. CAUTION: Use of controls and adjustments, or doing procedures other than those specified herein, may result in hazardous radiation exposure.

Drive Mechanism Assembly

Laser Beam Radiation

Laser Pickup Turntable

CAUTION
LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM.
Location: Top of DVD mechanism.
