1.General
1.General
1-1. Product specification
System
Model Number of effective pixels CCD sensor Number of recorded pixels

FinePix S5000 Service Manual

Storage media File format

Lens Aperture Focal length Focal range

Shutter speed Focus Sensitivity

Photometry Exposure control Exposure compensation White balance Viewfinder LCD monitor Flash

Self-Timer A/V output

Digital camera FinePix S5000 3.1 million pixels 1/2.7 inch Super CCD HR in an interwoven pattern Number of total pixels 3.14 million pixels Still image : 2816 ´ 2120 pixels/2048 ´ 1536 pixels/1600 ´ 1200 pixels/ 1280 ´ 960 pixels ( / / / ) Movie : 320 ´ 240 pixels (30 frames per second with monaural sound) xD-Picture Card (16/32/64/128/256/512 MB) Still image : Compressed : JPEG (Exif ver. 2.2) Uncompressed : CCD-RAW (RAF) * Design rule for Camera File System compliant DPOF compatible Movie : AVI format, Motion JPEG Audio : WAVE format, Monaural sound Fujinon 10´ optical zoom lens Aperture : F2.8 to F8 (Wide-angle) F3.2 to F9 (Telephoto) F2.8 to F8 10 steps in 1/3-EV increments Manual/Auto selectable f=5.7 mm to 57 mm (Equivalent to 37 mm to 370 mm on a 35 mm camera) Normal : Wide-angle : Approx. 0.9 m (3.0 ft.) to infinity Telephoto : Approx. 2.0 m (6.6 ft.) to infinity Macro : Wide-angle : Approx. 0.1 m to 2.0 m (0.3 ft. to 6.6 ft.) Telephoto : Approx. 0.9 m to 2.0 m (3.0 ft. to 6.6 ft.) Auto : 2 sec. to 1
/2000 sec. Manual : 2 sec. to 1/2000 sec. TTL contrast-type, Auto focus, Manual focus Manual : Equivalent to ISO200/400/800 (Image quality fixed at for shots taken at ISO 800.) Auto : Equivalent to ISO160-200 (at flash off) Equivalent to ISO200-400 (at flash on) TTL 64-zones metering Multi, Spot, Average Program AE ( , P, SP), Shutter-priority AE, Aperture-priority AE, Manual exposure -2.0 EV to +2.0 EV in 1/3 EV step increments (in Manual mode) AUTO ( , SP) Manual modes, 7 positions can be selected 0.33 inches 114,000 pixels electronic viewfinder 1.5-inches, low-temperature polysilicon TFT 114,000 pixels, 90% coverage Auto flash using flash control sensor Effective range : Wide-angle : Approx. 0.3 m to 6.0 m (1.0 ft. to 19.7 ft.) (Approx. 0.3 m to 2.0 m (1.0 ft. to 6.6 ft.) : Macro) Telephoto : Approx. 0.8 m to 5.5 m (2.6 ft. to 18.0 ft.) Flash modes : Auto, Red-eye reduction, Forced flash, Suppressed flash, Slow synchro, Red-eye reduction + Slow synchro 10 sec. NTSC/PAL selectable

Input/OutputTerminals
A/V output socket (USB) socket DC Input 2.5 mm dia. jack For file transfer to a computer Socket for specified AC power adapter AC-5VH/AC-5VHS (sold separately)

4

FinePix S5000 Service Manual Power Supply and Others
Power supply

1.General

Use one of the following : · 4´ AA-size alkaline batteries · 4´ AA-size Ni-MH (Nickel-Metal Hydride) batteries (sold separately) · AC Power Adapter AC-5VH/AC-5VHS (sold separately)
Battery Type
Alkaline batteries Ni-MH batteries 2100 mAh

Guide to the number of available frames for battery operation

With LCD monitor ON
Approx. 260 frames Approx. 420 frames

With viewfinder (EVF) ON
Approx. 270 frames Approx. 440 frames

The number of available shots for battery operation given here is a guide to the number of consecutive shots that can be taken under FUJIFILM test conditions. · Batteries used : Using the alkaline batteries bundled with the camera Using Ni-MH batteries at full charge · Shooting conditions : Measured at normal temperature with 50% flash use · Note : The number of available shots varies depending on the capacity of the alkaline batteries and the amount of charge in the Ni-MH batteries. Consequently, FUJIFILM makes no guarantee with regard to the numbers of available shots for battery operation given here. Note that the number of available shots will be lower at low temperatures. Conditions for use Temperature : 0oC to +40oC (+32oF to +104oF) ; 80% humidity or less (no condensation) Camera dimensions 112.7 mm ´ 81.1 mm ´ 79.3 mm/4.4 in. ´ 3.2 in. ´ 3.1 in. (W´H´D) (not including accessories and attachments) Cameramass(weight) Approx. 337 g/11.9 oz. (not including accessories, batteries and xD-Picture Card) Weig
ht for photography Approx. 479 g/16.9 oz. (including batteries and xD-Picture Card) Accessories LR6 AA-size alkaline batteries (4) 16 MB, xD-Picture Card (1) included with : Anti-static case (1) Shoulder strap (1) Adapter Ring : AR-FX5 (1) Lens Cap (1) A/V Cable for FinePix S5000 (approx. 1.5 m (4.9 ft.), plug (2.5 mm dia.) to pin-plug cable ´2) (1) USB cable (Mini-B) (1) CD-ROM : Software for FinePix SX (1) Owner's Manual (1) Optional Accessories xD-Picture Card DPC-16 (16 MB)/DPC-32 (32 MB)/DPC-64 (64 MB)/DPC-128 (128 MB)/ DPC-256 (256 MB)/DPC-512 (512 MB) Fujifilm Rechargeable Battery 2HR-3UF (2´) Fujifilm Battery charger with Battery BK-NH/BK-NH2 (With Euro type or UK type plug) AC Power Adapter AC-5VH/AC-5VHS Carrying Case SC-FXS5 Image Memory Card Reader DPC-R1 · Compatible with Windows 98/98 SE, Windows Me, Windows 2000 Professional, Windows XP or iMac, Mac OS 8.6 to 9.2.2, Mac OS X (10.1.2 to 10.1.5) and models that support USB as standard. · Compatible with xD-Picture Card of 16 MB to 512 MB, and Sm
artMedia of 3.3V, 4 MB to 128 MB. PC Card Adapter DPC-AD · Compatible with xD-Picture Card of 16 MB to 512 MB, and SmartMedia of 3.3V, 2 MB to 128 MB. CompactFlash Card Adapter DPC-CF · Windows 95/98/98 SE/Me/2000 Professional/XP · Mac OS 8.6 to 9.2.2/X (10.1.2 to 10.1.5) Standard number of available frames /recording time per xD-Picture Card
The number of available shots, recording time or file size varies slightly depending on the subjects photographed. Note also that the divergence between standard number of available shots and the actual number of available shots is greater for xD-Picture Cards with higher capacities. Quality mode Number of recorded pixels Image Data Size DPC-16 (16 MB) DPC-32 (32 MB) DPC-64 (64 MB) DPC-128 (128 MB) DPC-256 (256 MB) DPC-512 (512 MB) 2816 2120 10 21 43 86 173 347 2048 1536 19 40 81 162 325 651 1600 1200 25 50 101 204 409 818 1280 960 33 68 137 275 550 1101 1.5 MB 780 KB 630 KB 470 KB CCD-RAW 2816 2120 2 4 9 18 37 75 6.7 MB 26 sec. 54 sec. 109 sec. 219 sec. 7.3 min. 14.6 min. Movie 320 240

5

1.General
Explanation of Terms
AF/AE Lock :

FinePix S5000 Service Manual

On the FinePix S5000, pressing the shutter button down half way locks the focus and exposure settings (AF and AE lock). If you want to focus on a subject that is not centered in the frame or change the picture composition after the exposure is set, you can obtain good results by changing the composition after the AF and AE settings are locked. Auto Power Save Function : If the camera is not used in any way for 30 seconds, this function switches features such as the monitor off (Sleep mode) to prevent battery depletion and the waste of power when the AC power adapter is connected. If the camera is then left unused for a further period, the Auto Power Save function switches the camera off. This period can be set to 2 minutes or 5 minutes on this camera. The Auto Power Off function does not operate in PC mode, during automatic playback, or if it is disabled during setup. Deactivated batteries: Leaving an Ni-MH battery unused in storage for a long period may cause a rise in the level of substances that inhibit c
urrent flow inside the battery and result in a dormant battery. A battery in this state is referred to as deactivated. Because current flow is inhibited in a deactivated Ni-MH battery, the battery's original level of performance cannot be achieved. DPOF: Digital Print Order Format DPOF is a format used for recording information on a storage media (image memory card, etc.) that allows you to specify which of the frames shot using a digital camera are to be printed and how many prints are made of each image. EV: A number that denotes Exposure Value. The EV is determined by the brightness of the subject and sensitivity (speed) of the film or CCD. The number is larger for bright subjects and smaller for dark subjects. As the brightness of the subject changes, a digital camera maintains the amount of light hitting the CCD at a constant level by adjusting the aperture and shutter speed. When the amount of light striking the CCD doubles, the EV increases by 1. Likewise, when the light is halved, the EV decreases by
1. Frame rate (fps) : The frame rate refers to the number of images (frames) that are photographed or played back per second. For example, when 10 frames are continuously photographed in a 1-second interval, the frame rate is expressed as 10 fps. For reference, TV images are displayed at 30 fps. JPEG : Joint Photographics Experts Group A file format used for compressing and saving color images. The higher the compression rate, the greater the loss of quality in the decompressed (restored) image. Memory effect: If an Ni-MH battery is repeatedly charged without first being fully discharged, its performance may drop below its original level. This is referred to as the "memory effect". Motion JPEG: A type of AVI (Audio Video Interleave) file format that handles images and sound as a single file. Images in the file are recorded in JPEG format. Motion JPEG can be played back by QuickTime 3.0 or later. PC Card: A generic term for cards that meet the PC Card Standard. PC Card Standard: A standard for PC cards deter
mined by the PCMCIA. PCMCIA: Personal Computer Memory Card International Association (US). Smear : A phenomenon specific to CCDs whereby white streaks appear on the image when there is a very strong light source, such as the sun or reflected sunlight, in the photography screen. WAVE : A standard format used on Windows systems for saving audio data. WAVE files have the ".WAV" file extension and the data can be saved in either compressed or uncompressed format. Uncompressed recording is used on this camera. WAVE files can be played back on a personal computer using the following software: Windows: MediaPlayer Macintosh: QuickTime Player *QuickTime 3.0 or later White Balance: Whatever the kind of the light, the human eye adapts to it so that a white object still looks white. On the other hand, devices such as digital cameras see a white subject as white by first adjusting the color balance to suit the color of the ambient light around the subject. This adjustment is called matching the white balance. A function
that automatically matches the white balance is called an Automatic White Balance function. Exif Print: Exif Print Format is a newly revised digital camera file format that contains a variety of shooting information for optimal printing.
