Fujifilm FinePix S5000 Troubleshooting Guide

Automated PDF to Text preview page 4 to 6:

FinePix S5000 TROUBLESHOOTING GUIDE ! 1-1 Mode Select Problem

Problem Play mode even when Camera mode is selected. Cause Damage to SW952 on RSW PWB.

SW952

RSW board Repair Method Replace SW952.

Damaged SW952

4

FinePix S5000 TROUBLESHOOTING GUIDE 1-2 Mode Select Problem

Problem Play mode even when Camera mode is selected. Cause Damage to SW952 on RSW PWB due to R CABINET hook catching during assembly process. Soldered portion damaged simultaneously.

Enlarged view of damaged portion of SW952 Repair Method Replace SW952.

1-3

Mode Select Problem

Problem Mode dial select problem (not consistent with display). Sometimes selects without touching dial. Cause Contact problem with KSW PWB connector (CN801). Repair Method Clean KSW PWB connector (CN801).

5

FinePix S5000 TROUBLESHOOTING GUIDE 1-4 Key Doesn't Work

Problem `+' key doesn't work. Cause CONTACT SHEET B shorting components on MAIN PWB due to K SHEET 2 at bottom-right of MAIN PWB having been affixed in incorrect position.

K SHEET 2 and CONTACT SHEET B affixed on battery box side.

Align with edge of MAIN PWB and bottom GND terminal face of C235 and affix K SHEET 2.

Align with edge of MAIN PWB and affix CONTACT SHEET B on K SHEET 2.

Correct Positions for affixing K SHEET 2 and CONTACT SHEET B Repair Method Reaffix K SHEET 2 and CONTACT SHEET B in correct positions.

6
