Before You Begin: Dell Latitude D600 Service Manual

8. Remove any installed PC Cards from the PC Card slot. 9. Close the display and turn the computer upside down on a flat work surface. NOTICE: To avoid damaging the system board, you must remove the main battery before you service the computer. 10. Slide and hold the battery-bay latch release on the bottom of the computer, and then remove the battery from the bay.

11. Remove any installed memory modules, Mini PCI cards, and modules, including a second battery if one is installed. 12. Remove the hard drive.

Recommended Tools
The procedures in this manual require the following tools:
q

#1 Phillips screwdriver ¼-inch flat-blade screwdriver Small plastic scribe Flash BIOS update program floppy disk or CD

q

q

q

http://support.jp.dell.com/docs/systems/latd600/sm/begin.htm (2 de 6)24/04/2005 8:27:54

Before You Begin: Dell Latitude D600 Service Manual

Computer Orientation

1 2 3 4

back right front left

Screw Identification
When you are removing and replacing components, photocopy "Screw Identification" as a tool to lay out and keep track of the screws. The placemat provides the number of screws and their sizes.

http://support.jp.dell.com/docs/systems/latd600/sm/begin.htm (3 de 6)24/04/2005 8:27:54

Before You Begin: Dell Latitude D600 Service Manual

Optional Module: (1 each)

Hard Drive: (1 each)

Keyboard: (2 each)

Display Assembly: (3 each)

Display Bezel: (6 each)

Display Panel: (4 each)
