CMP420V1/CMP420V2/42EDT41 (PW1A)

2. Specifications
Panel Display dimensions Resolution Net dimensions (excluding Speakers/Stand) Net weight (excluding Speakers/Stand) Ambient conditions Power supply Power consumption/at standby Audio output (RGB input) RGB1 DVI input terminal (DVI-D) RGB1 audio input terminal (3.5mm Stereo Mini Jack) RGB2 analog RGB input terminal (D-sub 15-pin) RGB2 audio input terminal (3.5mm Stereo Mini Jack) 0.7 V/1.0 Vp-p, analog RGB (Recommended Signal) 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60 H/V separate, TTL level [2K ] H/V composite, TTL level [2K ] Sync on green, 0.3 Vp-p [75 ] AV1: composite video input terminal (RCA) AV1: Y PB PR video input terminal (RCA) AV1: L/R audio input terminal (RCA) AV2: composite video input terminal (RCA) AV2: Y/G PB/B PR/R video input terminal (RCA) AV2: L/R audio input terminal (RCA) AV3: composite video input terminal (RCA) AV3: S video input terminal (RCA) AV3: L/R audio input terminal (RCA) AV4: composite video / S video / RGB / L/R audio input terminal (Scart) AV1: NTSC-M, PAL-M, PAL-
N AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60 AV2: NTSC-M, PAL-M, PAL-N AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB AV3: NTSC-M, PAL-M, PAL-N AV4: NTSC-M, PAL-M, PAL-N AV4: RGB OUTPUT (MONITOR): composite video monitor-output terminal (RCA) OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA) AV4: composite video / L/R audio monitor-output terminal (SCART) Temperature Relative humidity Approx. 42 inches (920 (H) x 518 (V) mm, diagonal 1059mm) 852 (H) x 480 (V) pixels 1030 (W) x 636 (H) x 91 (D) mm CMP420V1/V2:33.2kg 42EDT41:34.2kg Operating : 5 to 35 , Storage : -15 to 60

Operating : 20% to 80%, Storage : 20% to 90% (non-condensing) AC100 - 240V, 50/60Hz 310W / <3W 12W + 12W (6 )

Input terminals

Input signals

Video signals

Sync signals (Video input)

Input terminals

Input signals

Video signals

Video output Signal (RF input) Input terminals Input signals RF Video System

ANT : 75 NTSC-M

unbalanced

Applicable video signals for each input terminal
Terminal Signal AV1 AV2 AV3 AV4 RGB1 RGB2 ( :Available) CVBS RCA/SCART S-video Component RGB PC DVI STB RGB D-sub Component

4

CMP420V1/CMP420V2/42EDT41 (PW1A)

3. Component names
[Main unit] Control panel
· Adjustment buttons are located on the bottom. · The back cover is provided with indications to distinguish the adjustment buttons.

Remote-control receiver Indicating lamp
· The main power switch is located at the back, on the lower surface.
OK

Rear Label

-

+

Main power switch

1. SUB POWER 2. VOL 2. ADJ 3. VOL 3. ADJ 4. PROGRAM 4. SELECT 5. PROGRAM 5. SELECT 6. INPUT SELECT 6. OK 7. MENU

1

2

3

4

5

6

7

NOTE: 1st number indicates normal button operation 2nd number indicates function during MENU

[Remote control]

for CMP420V1 CMP420V2 for 42EDT41

5

CMP420V1/CMP420V2/42EDT41 (PW1A)

4. Service points
Lead free solder
This product uses lead free solder (unleaded) to help preserve the environment. Please read these instructions before attempting any soldering work. Caution: Always wear safety glasses to prevent fumes or molten solder from getting into the eyes. Lead free solder can splatter at high temperatures (600°C).

Lead free solder indicator
Printed circuit boards using lead free solder are engraved with an "F."

Properties of lead free solder
The melting point of lead free solder is 40-50°C higher than leaded solder.

Servicing solder
Solder with an alloy composition of Sn-3.0Ag-0.5Cu or Sn-0.7Cu is recommended. Although servicing with leaded solder is possible, there are a few precautions that have to be taken. (Not taking these precautions may cause the solder to not harden properly, and lead to consequent malfunctions.) Precautions when using leaded solder Remove all lead free solder from soldered joints when replacing components. If leaded solder should be added to existing lead free joints, mix in the leaded solder thoroughly after the lead free solder has been completely melted (do not apply the soldering iron without solder).

Servicing soldering iron
A soldering iron with a temperature setting capability (temperature control function) is recommended. The melting point of lead free solder is higher than leaded solder. Use a soldering iron that maintains a high stable temperature (large heat capacity), and that allows temperature adjustment according to the part being serviced, to avoid poor servicing performance. Recommended soldering iron: Soldering iron with temperature control function (temperature range: 320-450°C) Recommended temperature range per part:

Part Mounting (chips) on mounted PCB Mounting (chips) on empty PCB Chassis, metallic shield, etc.

Soldering iron temperature 320°C±30°C 380°C±30°C 420°C±30°C

The PWB assembly which has used lead free solder (1) FILTER PWB, SW PWB, LED/RECEIVER PWB, TACT SW PWB, SP TERMINAL(L/R) PWB (2) AUDIO PWB, JOINT PWB (3) VIDEO PWB (4) FORMATTER PWB (5) POWER BOARD

6
