Husqvarna SC18 Sod Cutter Workshop / Service Manual - Download !!

Husqvarna SC18 Sod Cutter Workshop / Service Manual - Download !!

Sod cutting cuts out existing sod by slicing a layer of soil with the grass and roots so it can be rolled up and removed. Some applications could be for replacing a type of grass, turf removal, adding a sidewalk or pathway, installing swimming pools or laying pipes or sprinklers. The usual cutting depth is about 1 1/2 inches but can be used as deep as 2 1/2 inches. This application is ideal for brick laying. The advantage in using a sod cutter is that it does not disturb the soil beneath the cut.


Husgvarna's Sod Cutter has a four-speed transmission (two for cutting) with power reverse. The cutting path is 18 inches wide. Low speed will cut 175 ft /min while second gear will cut 250 ft/min. The construction is of 7-gauge steel with l0-inch tractor tires and four-wheel drive.

Service manual covers:

Contents Page
Introduction 3
Features & Controls 6
Operating Instructions, Safety & Maintenance 7
Specifications & Tools 13
Main Frame
1 Handle Attachment 14
2 Throttle Cable Adjustment 15
Power Train
1 Axle Sprocket Location 16
2 Belt Keeper 16
3 Chain Idler 16
4 Chain Routing & Adjustment 17
5 Engine Removal 17
6 Upper Pulley Location 18
7 Sprocket Location 18
8 Transmission Adjustment & Replacement 19
Blade Drive
1 Blade Drive Assembly 20
2 Belt Tension 20
3 Blade Arm Replacement 21
4 Lower Pulley 21
5 Bearing & Lock Collar 22
6 T Drive Replacement 23
Depth Control
1 Depth Control 30
Illustrated Parts Lists 31
Troubleshooting 35


( VERY HIGH QUALITY MANUAL - BEST SERVICE MANUAL THAT YOU CAN GET ANYWHERE FOR THE MODELS MENTIONED - FULLY INDEXED, HYPERLINKED & SEARCHABLE - INSTANT DOWNLOAD - FULL DOWNLOAD SUPPORT AFTER PURCHASE!! )


1. Downloadable: YES
2. Compatible: All Versions of Windows & Mac
3. File Format: PDF
4. Requirements: Adobe PDF Reader
5. Language: English

Tags: sod, cutter
