Canon iR 2016 and 2020 Parts Manual.
After purchasing a new item, sometimes the product manuals can get caught up in the packaging and discarded or over time can get mislaid. Most of us think, I would never open up the product to find out what is wrong, so what do I really need my manual for? The assumption that your product manual is only for people with great technical skill is a misconception. Purchasing a parts manual for your copier can save time, money and aggravation.
The parts manual provides exploded diagrams with references to part numbers.
Contains 100 pages in pdf format of all the information you require to maintain your photocopier.
Print off one page or the whole manual.
ASSEMBLY LOCATION DIAGRAM
EXTERNAL COVERS, PANELS, ETC.
MACHINE FRONT PLATE
INTERNAL COMPONENTS 1
INTERNAL COMPONENTS 2
MACHINE REAR PLATE
LFET DOOR ASSEMBLY
PAPER FEEDER FRAME ASSEMBLY
MAIN DRIVE ASSEMBLY
FIXING DRIVE ASSEMBLY
CASSETTE FEEDER ASSEMBLY
PAPER PICK-UP ASSEMBLY
CASSETTE FEEDER ASSEMBLY(iR2020)
PAPER PICK-UP ASSEMBLY(iR2020)
MULTI FEED TRAY ASSEMBLY
PAPER DELIVERY ASSEMBLY
IMAGE PROCESSOR PCB ASSEMBLY
HVT PCB ASSEMBLY
