This serviceman's handbook for the KOBELCO hydraulic excavator provides maintenance and repair personnel with basic information concermng routine maintenance and repair of the KOBELCO machine.

This handbook is compiled for the user's convenience using extracts mainly from the Operators and Shop Manuals. For inspection and maintenance of the machine in the field, use this handbook as a reference to improve your work efficiency.

APPLICABLE MODELS :
SK60
SKlOO
SK120
SK200
SK220
SK120LC
SK200Lc
SK220LC

TABLE OF CONTENTS :
MACHINE SPECIFICATIONS
COMPONENTS SPECIFICATIONS
PERFORMANCE DATA
NOISE LEVEL DATA
WEIGHT OF COMPONENTS (DRY WEIGHT)
LUBRICATION VOLUME CHART
HYDRAULIC CIRCUITS AND COMPONENTS
PQ CURVE PUMP
DIMENSIONS FOR ATTACHMENT
MAINTENANCE STANDARDS
TRAVEL MAINTENANCE STANDARDS
HYDRAULIC CYLINDER
ELECTRIC SYSTEM DIAGRAM
WORKING RANGE OF ATTACHMENTS
LIFTING CAPACITY
COMPONENTS
PERFORMANCE INSPECTION STANDARD

Downloadable : YES
File Format : PDF
Requirements : PDF Reader
Compatible : Windows & Mac
Language : English
Total pages : 242
