Kobelco SK450-VI / SK450LC-VI / SK480-VI / SK480LC-VI Hydraulic Excavator Dynamic Acera Serviceman Handbook

This manual can be used by anyone from a first time owner/amateur to a professional https://www.tradebit.comy to read type,And give you all the information needed to do the procedure https://www.tradebit.comp this service manual handy and use it often. Performing routine,preventive maintenance will save you time & money by helping to prevent premature failure and unnecessary repairs.

*********************
Models Covered:

SK450-VI LS06- 01001
SK450Lc-VI YS06- 00901
SK480-VI LS06- 01001
SK480Lc-VI YS06- 00901

****************
Manual Contents:

1. GENERAL DIMENSIONS
2. SPECIFICATIONS AND PERFORMANCE
3. ENGINE SPECIFICATIONS
4. HYDRAULIC COMPONENTS SPECIFICATIONS & PERFORMANCE
5. PERFORMANCE TABLE
6. NOISE LEVEL
7. WEIGHT OF COMPONENTS
8. SPECIFED OIL AND GREASE, AND FIL TEA ELEMENT LST
9. SUMMARY OF MECHATRO CONTROL SYSTEM
10. MECHATRO CONTROLLER ADJUSTMENT
11. MEASUREMENT OF ENGINE SPEED
12. MEASUREMENT OF HYDRAULIC PRESSURE
13. MEASURING TRAVEL PERFORMANCES
14. MEASURING SWING PERFORMANCES
15. MEASURING ATTACHMENT OPERATING PERFORMANCES
16. MEASURING PERFORMANCES OF SWING BEARING
17. PERFORMANCE INSPECTION STANDARD TABLE
18. HYDRAULIC CIRCUIT AND COMPONENTS
19. ELECTRIC CIRCUIT DIAGRAM
20. ELECTRONICALLY CONTROLLED FUEL SYSTEM
21. DIMENSIONS OF ATTACHMENT
22. PIN AND BUSHING TABLE OF ATTACHMENT
23. MAINTENANCE STANDARD
24. WORKING RANGE
25. TIGHTENING TORQUES FOR CAPSCREWS AND NUTS
26. SCREW SIZE AND TOOLS NOMINAL SIZE
27. TIGHTENING TORQUES FOR NUTS AND SLEEVES
28. SPECIAL SPANNER FOR TUBE
29. SPECIAL TOOLS
30. APPLICATION OF SCREW LOCKING COMPOUND AND SEALING COMPOUND
31. SUCTION STOPPER
32. UPPER FRAME LIFTING JIG
33. ENGINE MOUNTING PEDESTAL

****************
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader
File Data

This file is sold by vstars, an independent seller on Tradebit.

File Size 10 megabytes
File Type PDF
