Theory of Operation Manual Konica Minolta Bizhub 160, Bizhub 160F, Bizhub 161, Bizhub 161F;
This manual is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Konica Minolta Bizhub 160, Bizhub 160F, Bizhub 161, Bizhub 161F copier.
You can print, zoom or read any diagram, picture or page from this Theory of Operation Manual. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Konica Minolta Bizhub 160, Bizhub 160F, Bizhub 161, Bizhub 161F photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

OUTLINE
1. System configuration
2. Product specifications
2.1 Bizhub 160 / bizhub 161
2.1.1 Main Unit
2.1.2 GDI Printer Function (bizhub 160 only)
2.1.3 PCL Printer Function (bizhub 161 only)
2.2 bizhub 160f / bizhub 161f
2.2.1 Main Unit
2.2.2 GDI Printer Function (bizhub 160f only)
2.2.3 PCL Printer Function (bizhub 161f only)
2.2.4 FAX Function
3. Paper path

COMPOSITION/OPERATION
4. Components
5. Drive
6. Operating Sequence
6.1 Copy Process
6.2 Print Start Sequence
6.2.1 When the pre-start control is not provided
6.2.2 When the pre-start control is provided
6.3 Print End Sequence
7. IC (Imaging Cartridge) section
7.1 Overview
7.2 PC Drum
7.3 Developing System
7.4 Detection of Toner Cartridge
7.4.1 Installation Detection
7.4.2 Interchangeability Detection
7.4.3 Toner Near Empty and Toner Empty Detection
7.5 Drum Charge
8. IR section
8.1 Image Data Processing
8.2 Exposure Components Section
8.3 Scanner Drive Mechanism
8.3.1 Scanner Drive Mechanism
8.4 Scanner Motor Drive Control
9. PH (Print Head) section
9.1 Construction
9.2 Laser Exposure Process
9.3 Laser Emission Timing
9.4 Laser Emission Area
9.4.1 Main Scanning Direction
9.4.2 Sub-scanning Direction
10. Paper take-up section
10.1 Tray 1
10.1.1 Paper Take-up Mechanism
10.1.2 Double Feed Preventive Mechanism
10.1.3 Paper Empty Detection
10.1.4 Paper Take-up Retry Function
11. Image transfer section
11.1 Overview
12. Fusing section
12.1 Overview
12.2 Fusing Temperature Control
12.2.1 Temperature Changes (Plain Paper Having a Length of 186 mm or More)
12.2.2 Temperature Control
12.2.3 Temperature Control Mode
12.2.4 Printing Temperature by Paper Type in Different Temperature Control Modes
12.2.5 Fusing Temperature Protect Control
13. Paper exit section
13.1 Paper Exit Mechanism
14. Miscellaneous
14.1 Cooling of the Printer Interior
14.2 Original Cover Open/Close Detection Mechanism
15. Data flow diagram

Numbers of pages: 116.
