Samsung CLX-6260 6260FD 6260ND 6260FR 6260FW Service Manual.
This manual, Samsung CLX 6260 Series/CLX 6260FD/6260ND/6260FR/6260FW, is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Samsung CLX 6260 Series/CLX 6260FD/6260ND/6260FR/6260FW copier.
You can print, zoom or read any diagram, picture or page from this Service Manual. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Samsung CLX 6260 Series/CLX 6260FD/6260ND/6260FR/6260FW photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

1) PRECAUTIONS
1.1. Safety warning
1.2. Caution for safety
1.2.1. Toxic material
1.2.2. Electric shock and fire safety precautions
1.2.3. Handling precautions
1.2.4. Assembly and Disassembly precautions
1.2.5. Disregarding this warning may cause bodily injury
1.3. ESD precautions

2) PRODUCT SPECIFICATION AND DESCRIPTION
2.1. Product Specification
2.1.1. Product Overview
2.1.2. Specifications
2.1.2.1. General Print Engine
2.1.2.2. Copy
2.1.2.3. Scan
2.1.2.4. Fax
2.1.2.5. Controller and Software
2.1.2.6. Paper Handling
2.1.2.7. Reliability and Service
2.1.2.8. Environment
2.1.2.9. Consumables
2.1.2.10. Maintenance Parts
2.1.2.11. Option
2.1.3. Model Comparison Table
2.2. System Overview
2.2.1. Front View
2.2.2. Rear View
2.2.3. Paper Path
2.2.4. System Layout
2.2.4.1. Feeding Section
2.2.4.2. Transfer Roller
2.2.4.3. Drive Unit
2.2.4.4. Fuser Unit
2.2.4.5. LSU (Laser Scanner Unit)
2.2.4.6. Toner Cartridge
2.2.5. Hardware configuration
2.2.5.1. Main board
2.2.5.2. 4 Line OPE Controller (CLX-6260ND_6260FD_6260FR)
2.2.5.3. GUI OPE Controller (CLX-6260FW)
2.2.5.4. Fax Board
2.2.5.5. Wireless LAN board (CLX-626xFW only)
2.2.5.6. SMPS board
2.2.5.7. HVPS board
2.2.5.8. ITB EEPROM PBA
2.2.5.9. HUB PBA
2.2.5.10. SD-CARD PBA (CLX-626xFW only)
2.2.5.11. Electrical Parts Location
2.2.6. Engine F/W Control Algorithm
2.2.6.1. Feeding
2.2.6.2. Transfer
2.2.6.3. Fusing
2.2.6.4. LSU
2.2.7. Software Descriptions
2.2.7.1. Software system overview
2.2.7.2. Architecture
2.2.7.3. Data and Control Flow

3) DISASSEMBLY AND REASSEMBLY
3.1. Precautions when replacing parts
3.1.1. Precautions when assembling and disassembling
3.1.2. Precautions when handling PBA
3.1.3. Releasing Plastic Latches
3.2. Screws used in the printer
3.3. Replacing the maintenance parts
3.3.1. Toner Cartridge
3.3.2. Waste Toner Container
3.3.3. ITB Unit
3.3.4. Fuser Unit
3.3.5. Pick up_Forward_Reverse roller
3.4. Replacing the main SVC parts
3.4.1. Left and Right cover
3.4.2. HVPS board
3.4.3. Outer Temperature Sensor
3.4.4. Main Board
3.4.5. SMPS Fan
3.4.6. SMPS board
3.4.7. ADF or RADF Unit
3.4.8. OPE Unit
3.4.9. Platen Unit
3.4.10. Middle Cover
3.4.11. LSU
3.4.12. Fuser Fan
3.4.13. Main Drive Unit
3.4.14. DRIVE-T1
3.4.15. Fuser Drive Unit
3.4.16. PH (Paper Handling) Drive Unit
3.4.17. Exit Unit
3.4.18. MP Pick-Up Unit

4) ALIGNMENT AND TROUBLESHOOTING
4.1. Alignment and Adjustments
4.1.1. Control panel
4.1.2. Understanding the status LED
4.1.3. JAM removal
4.1.3.1. Clearing original document jams
4.1.3.2. Clearing paper jams
4.1.4. Periodic Defective Image
4.1.5. Useful management tools
4.1.5.1. Using Samsung Easy Printer Manager (Windows and Macintosh only)
4.1.5.2. Using Samsung Printer Status (Windows only)
4.1.5.3. Using SyncThru Web Service (SWS)
4.1.6. Updating Firmware
4.1.6.1. Update the firmware by using the USB port
4.1.6.2. Update the firmware by using the network
4.1.7. Tech Mode (Diagnostic Mode)
4.1.7.1. Tech Mode (CLX-6260ND_FD_FR)
4.1.7.2. Tech Mode (CLX-6260FW)
4.2. Troubleshooting
4.2.1. Procedure of checking the symptoms
4.2.1.1. Basic Check List
4.2.2. Error Code and Troubleshooting
4.2.3. Image quality problems
4.2.4. Other errors

5) SYSTEM DIAGRAM
5.1. Block Diagram
5.2. Connection Diagram

6) REFERENCE INFORMATION
6.1. Tool for Troubleshooting
6.2. Glossary

Numbers of pages: 159.
