Panasonic LUMIX DMC-CM1 Service Manual

Instant Download
Price:
24.00
USD


Tradebit buyer protection fee included.
Pay with Credit Card


Instant Download from copierserv, digital version

Pay for Panasonic LUMIX DMC-CM1 Service Manual
9.8329 MB PDF File

Panasonic Lumix DMC-CM1 Service Manual & Repair Guide in PDF format, no scanned-in or bootlegged https://www.tradebit.comh Quality!
Model No. DMC-CM1EB
DMC-CM1EF
DMC-CM1EG

TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General Guidelines ----------------------------------------3
1.2. Leakage Current Cold Check ---------------------------3
1.3. Leakage Current Hot Check (See Figure. 1)--------3
2 Warning --------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ----------4
2.2. How to Replace the Lithium Ion Battery--------------5
3 Service Navigation------------------------------------------------6
3.1. Introduction --------------------------------------------------6
3.2. Important Notice -------------------------------------------6
3.3. General Description About Lead Free Solder
(PbF) -------------------------------------------------------- 10
3.4. How to Define the Model Suffix----------------------- 11
4 Specifications ---------------------------------------------------- 12
5 Location of Controls and Components------------------ 14
6 Service Fixture & Tools --------------------------------------- 15
6.1. Service Fixture and Tools ------------------------------ 15
6.2. When Replacing the Main P.C.B. Unit -------------- 15
7 Disassembly and Assembly Instructions--------------- 16
7.1. Disassembly Flow Chart-------------------------------- 16
7.2. P.C.B. Location ------------------------------------------- 16
7.3. Disassembly Procedure -------------------------------- 17
7.4. Removal of the MOS Unit------------------------------ 22
7.5. How to Use Servicing Tool for Assembling -------- 22
8 Measurements and Adjustments -------------------------- 25
8.1. Matrix Chart for Replaced Part and Necessary
Adjustment------------------------------------------------- 25
9 Maintenance ------------------------------------------------------ 26
9.1. Cleaning Lens and LCD Panel ----------------------- 26

Specifications
Language: English
Format: PDF
Pages:26
