Service Manual & Parts List Samsung SCX-5635 Series, SCX-5635FN, SCX-5635HN;
This manual, Samsung SCX-5635 Series, SCX-5635FN, SCX-5635HN, is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Samsung SCX-5635 Series, SCX-5635FN, SCX-5635HN.
You can print, zoom or read any diagram, picture or page from this Service & Parts List Manual. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Samsung SCX-5635 Series, SCX-5635FN, SCX-5635HN photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

1. PRECAUTIONS
1.1 Safety Warning
1.2 Caution for safety
1.2.1 Toxic material
1.2.2 Electric Shock and Fire Safety Precautions
1.2.3 Handling Precautions
1.2.4 Assembly / Disassembly Precautions
1.2.5 Disregarding this warning may cause bodily injury
1.3 ESD Precautions
1.4 Super Capacitor or Lithium Battery Precautions

2. PRODUCT SPECIFICATION AND FEATURE
2.1 Product Overview
2.1.1 Product Summary
2.2 Product Specifications
2.2.1 General Specifications
2.2.2 Software and Network
2.2.3 Print Specification
2.2.4 Scan Specification
2.2.5 Copy Specification
2.2.6 Telephone Specification
2.2.7 Fax Specification
2.2.8 Paper Handling
2.2.9 Consumables
2.2.10 Maintenance Parts
2.3 Model Comparison
2.4 System Overview
2.4.1 Hardware Configuration
2.4.2 Mechanic configuration

3. DISASSEMBLY AND REASSEMBLY
3.1 Disassembly and Reassemblyons on Disassembly
3.2 Maintenance Parts
3.3 Replacing a Maintenance Parts
3.3.1 Fuser Unit
3.3.2 ADF Pick up unit and rubber pad
3.3.3 Pick up roller
3.3.4 Transfer roller
3.3.5 Holder-Pad
3.4 General Disassembly
3.4.1 Cover
3.4.2 ADF Board
3.4.3 Scan Assy
3.4.4 Middle Cover
3.4.5 Main PBA
3.4.6 Fax board
3.4.7 SMPS board
3.4.8 Main Drive unit
3.4.9 HVPS board
3.4.10 LSU Unit

4. ALIGNMENT & TROUBLESHOOTING
4.1 Alignment and Adjustments
4.1.1 Control panel overview
4.1.2 Understanding The Status LED
4.1.3 Menu Overview
4.1.4 Tech Mode
4.1.5 Clearing Paper Jams
4.1.6 Abnormal Image Printing and Defective Roller
4.1.7 Error Message
4.2 Troubleshooting
4.2.1 Procedure of Checking the Symptoms
4.2.2 Solution

5. SYSTEM DIAGRAM
5.1 Block Diagram (Main I/F)
5.2 Block Diagram (SUB B'd)
5.3 Power Diagram

6. REFERENCE INFORMATION
6.1 Tool for Troubleshooting
6.2 Acronyms and Abbreviations
6.2.1 Acronyms
6.2.2 Service Parts
6.3 The Sample Pattern for the Test
6.4 Selecting a location

7. PARTS CATALOG
Harness Connection Table
Used Screw List
Tumbnail
1. Main
2. ELA HOU-Cover
3. ELA HOU-Cover Mid
4. MEA-Cover Front
5. MEA-Cover Rear
6. ELA HOU-Cover Side R
7. ELA HOU-Scan
8. ELA HOU-ADF
9. MEA-Cover Open
10. MEA Unit-Pick Up
11. MEA-ADF Upper
12. ELA HOU-ADF Lower
13. Drive ADF-Bracket
14. MEA Unit-Cover Platen
15. ELA HOU-Platen
16. MEA-Scan Upper
17. ELA HOU-Scan Lower
18. ELA HOU-Scan Motor
19. ELA HOU-OPE
20. ELA Unit-Main Drive
21. ELA Unit-Duplex Drive
22. ELA HOU-Frame
23. ELA HOU-Frame Etc.
24. ELA HOU-Frame Exit
25. ELA HOU-Guide_Dup F
26. ELA HOU-MPF
27. ELA HOU-Fuser Drive
28. ELA Unit-Fuser
29. MEA Unit-Bracket Feed
30. MEA Unit-Clutch
31. ELA HOU-SMPS_V1/V2
32. MEA Unit-Duplex
33. MEA Unit-Cassette
34. ELA HOU-SCF

Numbers of pages: 218.
