Service Manual & Parts List Samsung CLX-3160 Series;
This service manual, is the full Samsung CLX-3160 Series Service Repair Manual.
This manual, Samsung CLX-3160 Series, is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Samsung CLX-3160 Series copier.
You can print, zoom or read any diagram, picture or page from this Service Manual. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Samsung CLX-3160 Series photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

1. PRECAUTIONS
1.1 Safety Warning 1-1
1.2 Caution for safety 1-2
1.3 ESD Precautions 1-5
1.4 Super Capacitor or Lithium Battery Precautions 1-5

2. PRODUCT SPECIFICATION
2.1 Product Overview 2-1
2.2 Product General Specifications 2-2
2.3 Model Comparison Table 2-14

3. SYSTEM OVERVIEW
3.1 System Structure 3-1
3.2 Main PBA Description 3-14
3.3 CRUM 3-30
3.4 General Description 3-32

4. S/W STRUCTURE AND DESCRIPTIONS
4.1 Overview 4-1
4.2 Architecture 4-1
4.3 Data and Control Flow 4-2
4.4 Alarm Shortage 4-4
4.5 Error status 4-4
4.6 CRUM Overview 4-5
4.7 FW Upgrade 4-5
4.8 Initailize Flow 4-6

5. DISASSEMBLY AND REASSEMBLY
5.1 General Precautions on Disassembly 5-1
5.2 Cover Upper (Left, Right) 5-2
5.3 Front Cover 5-3
5.4 OPC DEV Unit 5-4
5.5 ITB Unit 5-5
5.6 T2 Roller Unit 5-6
5.7 Rear Cover 5-6
5.8 OPE Unit 5-7
5.9 Side Cover (Left, Right) 5-9
5.10 ADF Ass'y 5-10
5.11 Platen Ass'y 5-12
5.12 Middle Cover Ass'y 5-17
5.13 Fuser Ass'y 5-19
5.14 HVPS 5-21
5.15 LIU Unit 5-22
5.16 Shield Main Lower (with Main PBA) 5-23
5.17 Main Drive Ass'y 5-24
5.18 SMPS 5-25
5.19 Regi Roller 5-26
5.20 Feed Roller 5-28
5.21 Pick Up Roller 5-29
5.22 Exit Roller Unit 5-32
5.23 LSU 5-34
5.24 MP Unit 5-34

6. ALIGNMENT AND ADJUSTMENTS
6.1 Control Panel 6-1
6.2 LED Function 6-3
6.3 Jam Removal 6-4
6.4 System setup 6-10
6.5 Network setup 6-16
6.6 Sample Pattern 6-20
6.7 Periodic Defective Image 6-22
6.8 Tech Mode 6-23
6.9 Error Message 6-34

7. TROUBLESHOOTING
7.1 Procedure of Checking the Symptoms 7-1
7.2 Solving other problems 7-2

8. EXPLODED VIEWS & PARTS LIST
8.1 Main 8-2
8.2 Middle Cover 8-3
8.3 Front Cover 8-4
8.4 Right Cover 8-5
8.5 Round Cover 8-6
8.6 Rear Cover 8-7
8.7 Cover Platen 8-8
8.8 Platen Ass'y 8-9
8.9 OPE(CLX-3160FN) 8-10
OPE(CLX-3160N) 8-11
8.10 Scan Ass'y 8-12
8.11 ADF Ass'y 8-13
8.12 ADF Lower 8-14
8.13 ADF Motor 8-15
8.14 Frame 8-16
8.15 Main Driver 8-18
8.16 LSU Cover 8-20
8.17 ITB Unit 8-21
8.18 OPC DEVE 8-22
8.19 Fuser Ass'y 8-24
8.20 Cassette 8-25

9. BLOCK DIAGRAM
9.1 Block Diagram 9-1

10. CONNECTION DIAGRAM
10.1 Connection Diagram

11. REFERENCE INFORMATION
11.1 Tools for Troubleshooting 11-1
11.2 Acronyms and Abbreviations 11-2
11.3 Select a location for the printer 11-4
11.4 A4 ISO 19752 Standard Pattern 11-5
11.5 Wireless LAN 11-6

Numbers of pages: 161.
