Service Manual & Parts List Samsung SCX-5835, SCX-5835FN, SCX-5935, SCX-5935FN;
This service manual, is the full Samsung SCX-5835, SCX-5835FN, SCX-5935, SCX-5935FN Service Repair Manual.
This manual, Samsung SCX-5835, SCX-5835FN, SCX-5935, SCX-5935FN, is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Samsung SCX-5835, SCX-5835FN, SCX-5935, SCX-5935FN copier.
You can print, zoom or read any diagram, picture or page from this Service Manual. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Samsung SCX-5835, SCX-5835FN, SCX-5935, SCX-5935FN photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

1. PRECAUTIONS
1.1 Safety Warning
1.2 Caution for safety
1.3 ESD Precautions
1.4 Super Capacitor or Lithium Battery Precautions

2. PRODUCT SPEC AND FEATURE
2.1 Product Overview
2.1.1 Product Summary
2.1.2 Specifications
2.1.3 Model Comparison
2.2 System Overview
2.2.1 System Configuration
2.2.2 Hardware Configuration
2.2.3 Mechanic Configuration

3. DISASSEMBLY AND REASSEMBLY
3.1 Disassembly and Reassemblyons on Disassembly
3.2 Maintenance Parts
3.3 General Disassembly
3.3.1 Fuser Unit
3.3.2 DADF Pick up unit and rubber pad
3.3.3 Pick up roller
3.3.4 Transfer roller
3.3.5 Cover
3.3.6 DADF Board
3.3.7 Scan Assy
3.3.8 Middle Cover
3.3.9 HDD/ Main PBA/ Fax board
3.3.10 SMPS board
3.3.11 Main Drive unit
3.3.12 HVPS board
3.3.13 LSU Unit

4. ALIGNMENT & TROUBLESHOOTING
4.1 Alignment and Adjustments
4.1.1 Paper path
4.1.2 Clearing Paper Jams
4.1.3 Abnormal Image Printing and Defective Roller
4.1.4 Control Panel overview
4.1.5 Understanding The Status LED
4.1.6 Menu overview
4.1.7 Firmware Upgrade
4.1.8 Diagnostics
4.2 Troubleshooting
4.2.1 Procedure of Checking the Symptoms
4.2.2 Error Message
4.2.3 Solution

5. SYSTEM DIAGRAM
5.1 Block Diagram
5.2 Connection Diagram

6. REFERENCE INFORMATION
6.1 Tool for Troubleshooting
6.2 Acronyms and Abbreviations
6.2.1 Acronyms
6.2.2 Service Parts
6.3 The Sample Pattern for the Test
6.4 Selecting a location

PARTS CATALOG
Maintenance Parts and Option Unit
1. Main
2. Cover
3. ELA HOU COVER MID
4. ELA HOU-COVER REAR UP
5. ELA HOU-LOWER DUMMY
6. MEA COVER FRONT
7. MEA COVER MID FRONT
8. MEA COVER REAR
9. MEA COVER SIDE R_L
10. ELA HOU SCAN
11. ELA HOU DADF
12. ELA HOU-DADF UPPER
13. ELA HOU-DADF DRV
14. ELA_HOU_DADF_LOWER
15. ELA_HOU_COVER_PLATEN
16. ELA HOU-PLATEN
17. ELA HOU-SCAN LOWER
18. ELA HOU-OPE
19. ELA UNIT-MAIN DRIVE
20. ELA HOU-FRAME
21. ELA HOU-FRAME ETC
22. ELA HOU-FUSER DRIVE
23. ELA HOU-GUIDE DUP
24. ELA HOU-MPF
25. ELA_HOU_FRAME_EXIT
26. MEA UNIT-CLUTCH
27. MEA UNIT-BRACKET FEED
28. ELA UNIT-FUSER
29. MEA UNIT-DUPLEX
30. MEA UNIT-CASSETTE
31. ELA HOU-SCF

Numbers of pages: 229.
