Service Manual & Parts List Samsung CLX-2160 Series, CLX-2160N;
This manual is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Samsung CLX-2160 Series, CLX-2160N.
You can print, zoom or read any diagram, picture or page from this Service Manual & Parts List. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Samsung CLX-2160 Series, CLX-2160N. You can find easily everything what do you need.
To see what contain, please read table of contents:

1. PRECAUTIONS
1.1 Safety Warning
1.2 Caution for safety
1.3 ESD Precautions
1.4 Super Capacitor or Lithium Battery Precautions

2. PRODUCT SPEC AND FEATURE
2.1 Product Specifications
2.1.1 Product Special feature
2.1.2 Specifications
2.1.3 Model Comparison Table
2.2 Summary of Product
2.2.1 Printer Components
2.2.2 System Layout
2.2.3 Engine H/W Specifications
2.2.4 General Description

3. DISASSEMBLY AND REASSEMBLY
3.1 General Precautions on Disassembly
3.1.1 Screws used in the printer
3.2 Covers
3.3 Scan-Unit
3.4 Cover-Middle Unit
3.5 Fuser Unit
3.6 LSU (Laser Scan Unit)
3.7 HVPS (High Voltage Power Supply)
3.8 Main Controller PBA
3.9 SMPS
3.10 Drive Unit
3.11 Transfer Roller

4. ALIGNMENT & TROUBLESHOOTING
4.1 Alignment and Adjustments
4.1.1 Control Panel
4.1.2 LED Function
4.1.3 Jam Removal
4.1.4 System setup
4.1.5 Sample Pattern
4.1.6 Periodic Defective Image
4.1.7 Tech Mode
4.1.8 Error Message
4.2 Troubleshooting
4.2.1 Procedure of Checking the Symptoms
4.2.2 The cause and solution of image quality
4.2.3 The cause and solution of the paper feeding
4.2.4 Copy Problems
4.2.5 Scanner, OPE Problems
4.2.6 Other Problems

5. EXPLODED VIEWS & PARTS LIST
5.1 Main
5.2 Middle Cover
5.3.1 Rear Cover
5.3.2 Transfer Unit
5.4 Cover Unit
5.5 OPE
5.6 Scan Ass'y
5.7 Frame Assembly
Frame Assembly(Continued)
5.8 Main Driver
Main Driver(Continued)
5.9 LSU Cover
5.10 ITB Unit
5.11.1 OPC DEVE
5.11.2 DEVE Main Set
5.12 Toner Tank(C, M, Y)
5.13 Toner Tank(K)
5.14 Fuser Ass'y
5.15 Cassette

6. SYSTEM DIAGRAM
6.1 Block Diagram
6.1 Connection Dia ram

7. REFERENCE INFORMATION
7.1 Tool for Troubleshooting
7.2 Acronyms and Abbreviations
7.3 Select a location for the printer
7.4 A4 ISO 19752 Standard Pattern
7.5 Model List

Number of pages: 159.
