Service Manual & Parts List Samsung Digital Color Laser CLX 6220FX, CLX-6250FX is the full Service Repair Manual.
This manual, Samsung Digital Color Laser CLX-6220FX, CLX-6250FX, is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Samsung Digital Color Laser CLX-6220FX, CLX-6250FX copier.
You can print, zoom or read any diagram, picture or page from this Service Manual & Parts List. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Samsung Digital Color Laser CLX-6220FX, CLX-6250FX photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

CONTENTS FOR SERVICE MANUAL:
1) PRECAUTIONS
1.1 Safety warning
1.2 Caution for safety
1.3 ESD precautions
1.4 Super capacitor or lithium battery precautions

2) PRODUCT SPECIFICATION AND FEATURE
2.1 Product summary
2.2 Specifications
2.2.1 General Printer Engine
2.2.2 Controller & S/W
2.2.3 Interface
2.2.4 Scan
2.2.5 Copy
2.2.6 FAX
2.2.7 Paper Handling
2.2.8 Consumables
2.2.9 Maintenance parts
2.2.10 Reliability & Service
2.2.11 Environment
2.2.12 Packing & Accessory
2.2.13 Option
2.3 Model Comparison
2.4 Product configuration
2.4.1 Printer external
2.4.2 Hardware configuration
2.4.3 Feeding Section
2.4.4 LSU
2.4.5 Fuser Unit
2.4.6 PTB (Paper Transfer Belt) Unit
2.4.7 Motors
2.4.8 Sensors

3) MAINTENANCE AND DISASSEMBLY
3.1 Precautions when replacing parts
3.1.1 Precautions when assembling and disassembling
3.1.2 Preautions when handling PBA
3.1.3 Releasing Plastic Latches
3.2 Replacing a Maintenance Parts
3.2.1 Fuser Unit
3.2.2 Pick up roller
3.3 General Disassembly
3.3.1 Cover Unit
3.3.2 Scanner Ass'y
3.3.3 DADF
3.3.4 Reverse Ass'y
3.3.5 Cover Middle Ass'y
3.3.6 HVPS Board
3.3.7 Main board
3.3.8 SMPS Board
3.3.9 Fuser Control Board
3.3.10 LSU
3.3.11 SOLENOID
3.3.12 Drive-Exit Bracket
3.3.13 Drive-Fuser Bracket

4) ALIGNMENT AND TROUBLESHOOTING
4.1 Alignment and Adjustments
4.1.1 Control Panel
4.1.2 Understanding The Status LED
4.1.3 Menu Overview
4.1.4 Tech Mode
4.1.5 Firmware Upgrade
4.2 Troubleshooting
4.2.1 Procedure of Checking the Symptoms
4.2.2 Error code and message
4.2.3 Feeding Problems and solutions
4.2.4 Image Quality Problems and solutions
4.2.5 Common Problems and solutions
4.2.6 Network problems and solutions
4.2.7 Copy Problems
4.2.8 OPE Problems

5) SYSTEM DIAGRAM
5.1 Block Diagram
5.1.1 6250FX
5.1.2 6220FX
5.1.3 OPE
5.2 Connection diagram

6) REFERENCE INFORMATION
6.1 Tools for Troubleshooting
6.2 Acronyms and Abbreviations
6.3 Select a location for the printer
6.4 A4 ISO 19752 Standard Pattern

-----------

CONTENTS FOR PARTS LIST:
Power Cord
Harness connection table
Thumbnail
1. MAIN
2. COVER
3. COVER-FRONT ASSY
4. COVER-MP
5. COVER-MIDDLE ASSY
6. COVER-MIDDLE REAR ASSY
7. FRAME
8. FRAME_BOTTOM
9. FRAME LEFT
10. FRAME RIGHT
11. DRIVE_FUSER-BRACKET
12. DRIVE FEED
13. FUSER
14. ELA UNIT-REVERSE
15. ELA UNIT-MOTOR BRKT
16. ELA UNIT-FRAME REV
17. MEA UNIT-COVER TOP
18. SCANNER
19. OPE
20. DADF
21. DADF-COVER PLATEN
22. DADF STACKER-TX
23. DADF-UPPER
24. DADF-COVER OPEN
25. DADF-LOWER
26. PLATEN
27. PLATEN-UPPER
28. PLATEN-LOWER
29. CASSETTE

Number of pages: 237.
