Service Manual & Parts List Panasonic KX-MB262CX, KX-MB772CX;
This service manual, is the full Panasonic KX-MB262CX, KX-MB772CX Service Repair Manual.
This manual, Panasonic KX-MB262CX, KX-MB772CX, is in the PDF format and have detailed Diagrams, pictures and full procedures to diagnose and repair your Panasonic KX-MB262CX, KX-MB772CX copier.
You can print, zoom or read any diagram, picture or page from this Service Manual. Every chapter on this manual is fully detailed and contain all the simulation codes, trouble codes, maintenance procedures, reset procedures, diagnose procedures of Panasonic KX-MB262CX, KX-MB772CX photocopier. You can find easily everything what do you need.
To see what contain, please read table of contents:

1. SAFETY PRECAUTION
1.1. FOR SERVICE TECHNICIANS
1.2. AC CAUTION
1.3. PERSONAL SAFETY PRECAUTIONS
1.4. SERVICE PRECAUTIONS

2. WARNING
2.1. ABOUT LEAD FREE SOLDER (PbF: Pb free)
2.2. Discarding of P. C. Board
2.3. INSULATION RESISTANCE TEST
2.4. BATTERY CAUTION
2.5. LASER BEAM AND FUSER UNIT SECTION

3. SPECIFICATIONS
4. GENERAL/INTRODUCTION
4.1. OPTIONAL ACCESSORIES

5. FEATURES
5.1. General Features
5.2. HARDWARE REQUIREMENTS FOR MULTIFUNCTION SOFTWARE

6. TECHNICAL DESCRIPTIONS
6.1. CONNECTION DIAGRAM
6.2. GENERAL BLOCK DIAGRAM
6.3. MAIN BOARD SECTION
6.4. NCU SECTION (KX-MB772CX ONLY)
6.5. ITS (Integrated telephone System) and MONITOR SECTION (KX-MB772CX ONLY)
6.6. CIS CONTROL SECTION
6.7. MOTOR DRIVE SECTION
6.8. TIMING CHART AND WAVE FORM OF SCANNER MOTORS
6.9. FAN MOTOR SECTION
6.10. SOLENOID DRIVER SECTION
6.11. LSU (Laser Scanning Unit) SECTION
6.12. SENSORS AND SWITCHES SECTION
6.13. OPERATION BOARD SECTION
6.14. LCD SECTION
6.15. HVPS (High Voltage Power Supply) SECTION
6.16. HEAT LAMP CONTROL CIRCUIT
6.17. Main Board Section
6.18. POWER SUPPLY BOARD SECTION
6.19. Mechanical Operation

7. LOCATION OF CONTROLS AND COMPONENTS
7.1. OVERVIEW
7.2. CONTROL PANEL

8. INSTALLATION INSTRUCTIONS
8.1. INSTALLATION
8.2. CONNECTIONS

9. OPERATION INSTRUCTIONS
9.1. YOUR LOGO (KX-MB772CX only)

10. TEST MODE
10.1. TEST FUNCTIONS

11. SERVICE MODE
11.1. PROGRAMMING AND LISTS
11.2. USER MODE (The list below is an example of the SYSTEM SETUP LIST the unit prints out.)
11.3. SERVICE MODE SETTINGS (Example of a printed out list)
11.4. HISTORY

12. TROUBLESHOOTING GUIDE
12.1. USER RECOVERABLE ERRORS
12.2. REMOTE PROGRAMMING (KX-MB772CX ONLY)
12.3. TROUBLESHOOTING DETAILS
12.4. DOCUMENT JAMS (AUTO DOCUMENT FEEDER) (KX-MB772CX ONLY)
12.5. RECORDING PAPER JAM

13. SERVICE FIXTURE & TOOLS

14. DISASSEMBLY AND ASSEMBLY INSTRUCTIONS
14.1. ADF SECTION
14.2. REMOVE ADF SECTION (1)
14.3. REMOVE ADF SECTION
14.4. REMOVE TOP COVER SECTION
14.5. REMOVE SCANNER GLASS SECTION
14.6. REMOVE OPERATION PANEL SECTION
14.7. LEFT SIDE SECTION
14.8. REMOVE MAIN BOARD
14.9. REMOVE GEAR CHASSIS SECTION
14.10. REMOVE PAPER FEED ROLLER
14.11. RIGHT SIDE SECTION
14.12. REMOVE RIGHT SIDE COVER SECTION
14.13. LOWER SIDE CABINET SECTION
14.14. REMOVE RIGHT CASSETTE GUIDE
14.15. REMOVE PICK UP BOARD
14.16. REMOVE HIGH VOLTAGE POWER BOARD
14.17. REMOVE PICK UP ROLLER UNIT
14.18. REMOVE LOW VOLTAGE POWER BOARD
14.19. REMOVE FUSER UNIT
14.20. Installation Position of The Lead

15. MAINTENANCE
15.1. MAINTENANCE ITEMS AND COMPONENT LOCATIONS
15.2. MAINTENANCE
15.3. PRINTING OPERATION PRINCIPLE
15.4. TERMINAL GUIDE OF THE ICs TRANSISTORS AND DIODES
15.5. HOW TO REPLACE THE FLAT PACKAGE IC
15.6. MAIN BOARD SECTION
15.7. TEST CHART

16. SCHEMATIC DIAGRAM
16.1. For Schematic Diagram
16.2. KX-MB262CX MAIN BOARD
16.3. KX-MB772CX MAIN BOARD
16.4. OPERATION BOARD
16.5. SENSOR BOARD

17. PRINTHEAD CIRCUIT BOARD
17.1. MAIN BOARD
17.2. OPERATION BOARD
17.3. SENSOR BOARD

18. EXPLODED VIEW AND REPLACEMENT PARTS LIST
18.1. CABINET, MECHANICAL AND ELECTRICAL PARTS LOCATION
18.2. REPLACEMENT PARTS LIST

Number of pages: 288.
