Linde Electric Pallet Truck Type 1152: T16L Operating Instructions (User Manual)

Original Illustrated Factory Operating Instructions (User Manual) for Linde Electric Pallet Truck Type 1152.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
T16L

Format: PDF, 136 Pages
Language: English

Contents:

1. Introduction
Your Linde truck
Impermissible use
Description of use and climatic conditions
Symbols used
Legal requirements for placing on the market
Receiving the industrial truck
Technical description
2. Safety
Residual risks
Periodic general checks on trucks
Handling consumables
Safety regulations
Stability
3. General views
Labels
General view
Controls
Battery charge indicator
Digicode option (LFM Go)
LFM Access-LFM Basic option
4. Use
Checks before first use
Daily checks before use
Adjusting the on-board charger
Using the charger
Start-up
Emergency stop handle
Direction of travel
Creep Speed (option)
Proportional Speed function
Steering
Use of the truck on a slope
Braking system
Using the load arms and forks
Using the horn
Fork manual lifting and lowering (side buttons)
Fork automatic lifting and lowering
Capacity
Workingwithloads
Order picking
Hoisting, towing
5. Maintenance
Maintenance
Calendar of testing and maintenance operations
Technical inspection and maintenance characteristics
Recommended lubricants
Daily checks before starting work
Checking the directionoftravelcontrols
Checking the lifting and lowering controls
Testing the safety devices
Maintenance plan as required
Cleaning the truck
Cleaning the battery and its compartment
Access to the technical compartment
Accessing the reducer and the brake
Checking the fuses
Checking the battery charging status
Opening the battery cover
Disconnecting/connecting the battery connector .
Battery with vertical access; removal-refitting
Side access battery: changing the battery using a trolley
Side access battery: changing the battery using a moveable support .
Battery charging using an external charger
Charging the battery using the on-board charger .
Inspection and maintenance overview
1000 hour service plan
2000 hour service plan
5000 hour service plan
Gearbox
Servicing the reducer .
Steering / braking / wheels
Check braking
Check the brake air gap
Adjusting the height of the stabilisers
Electrical equipment
Checking the on-board charger
Checking the condition of cables, terminals and battery connector
Battery maintenance .
Hydraulic circuit
Checking the oil level
Draining the hydraulic circuit
Cleaning the hydraulic filter
Mast/Chains
Specific mast maintenance
Lifting system
Checking the wear on collar sandhingepins
Greasing the rings and articulations (greasedoption)
6. Datasheet
Technical datasheet T16L

Annex
7. Diagrams
Circuit diagram parts list
T16L
T16L options
LFM options on T16L
T16L with automatic lifting/lowering of the fork
T16L options with automatic lifting/lowering of the fork
LFM options on T16L equipped with automatic lifting/lowering
Hydraulic diagram .
