Clark TMX12, TMX13, TMX15s, TMX15, TMX17, TMX18, TMX20, TMX20x, TMX25 Forklift Trucks Workshop Service Repair Manual

Instant Download
Price:
14.95
USD


Tradebit buyer protection fee included.
Pay with Credit Card


Instant Download from filepc, digital version

Pay for Clark TMX12, TMX13, TMX15s, TMX15, TMX17, TMX18, TMX20, TMX20x, TMX25 Forklift Trucks Workshop Service Repair Manual
20.9529 MB PDF File

This is the COMPLETE factory Service Repair Manual for the Clark TMX12, TMX13, TMX15s, TMX15, TMX17, TMX18, TMX20, TMX20x, TMX25 Forklift Trucks. This manual is very detailed and contains information and data to this model. has specs, diagrams, and actual real photo illustrations, and schemes. which give you complete step by step operations on repair, assembly, disassembly, diagnosing, servicing, technical maintenance & troubleshooting procedures for your machine.

Models Covered:
=========
Clark TMX12 Forklift Truck
Clark TMX13 Forklift Truck
Clark TMX15s Forklift Truck
Clark TMX15 Forklift Truck
Clark TMX17 Forklift Truck
Clark TMX18 Forklift Truck
Clark TMX20 Forklift Truck
Clark TMX20x Forklift Truck
Clark TMX25 Forklift Truck

This Manual Covers:
=========
SA SAFE MAINTENANCE
1. Safety
2. Lifting, Jacking, and Blocking the Truck
3. Towing
PS PERIODIC SERVICE
1. Maintenance Schedules
2. Planned Maintenance Program
3. PM Inspection Form
12 BATTERY
1. Battery Service
13 WIRING, SWITCHES, AND INSTRUMENTS
1. Schematic Electric Circuit Diagrams
2. General Electrical Service Tips
3. Wiring and Cables
4. Switches and Sensors
5. Instrument Panel
16 ELECTRIC MOTORS
1. Motor Specifications And Descriptions
2. Drive Motors Overhaul
3. Pump Motor Overhaul
17 CONTACTORS
1. Contactors
19 MOTOR CONTROLS
1. Description
2. Programming & Adjustments Using ZAPI Handset
3. Control troubleshooting
4. TMX Factory Control Settings
20 DRIVE AXLE
1. Drive Axle Specifications and Description
2. Drive Axle Fluid Check and Change
3. Drive Axle Troubleshooting
4. Drive Axle Removal and Installation
5. Drive Axle Overhaul
22 WHEELS AND TIRES
1. Wheels & Tires Specifications and Description
2. Wheels & Tires Mounting and Maintenance
23 BRAKE SYSTEM
1. Brake Specifications
2. Brake System Fluid Check, Fill, and Bleed Specifications and Description
3. Brake Pedal and Master Cylinder Removal, Replacement, and Adjustment
4. Brake Caliper Removal and Replacement
5. Parking Brake Removal, Replacement, and Adjustment
6. Brake Overhaul
25/26 STEER SYSTEM
1. Steering System Specifications and Description.
2. Steering System Troubleshooting
3. Steering Column and Component Removal and Replacement
4. Steering System Relief Pressure Check and Adjustment
5. Steering Gear Overhaul
6. Steer Axle Service
7. Steer Cylinder Overhaul
29 HYDRAULIC SYSTEM
1. Main Hydraulic System Specifications and Description
2. Fluids and Filters
3. Hydraulic System Troubleshooting Troubleshoot-ing
4. Hydraulic System Pressure Checks and Adjust-ments
5. Hydraulic System Removal and Overhaul
30 HYDRAULIC SYSTEM
1. Hydraulic System Schematic
2. Main Hydraulic Control Valve Removal and Overhaul
32 TILT CYLINDERS
1. Tilt Cylinder Specifications and Description
2. Checks and Adjustments
3. Tilt Cylinder Removal and Installation
4. Tilt Cylinder Overhaul
34 UPRIGHTS
1. Upright Specifications and Description
2. Trouble shooting
3. Upright Inspection
4. Carriage and Upright Roller Clearance Checks and Shim Adjustment
5. Cylinder Removal, Shimming, Overhaul and Replacement
6. Upright Chain Inspection, Adjustment and Replacement
7. Fork and Carriage Removal and Replacement
8. Upright Removal and Replacement
38 COUNTERWEIGHT AND CHASSIS
1. Counterweight Specifications and Description
2. Counterweight Removal and Installation
3. Overhead Guard Removal and Installation
4. Floor Plate, Seat, and Seat Deck Removal and Installation
40 SPECIFICATIONS
1. Nameplate and Decals
2. General Specifications
3. Hydraulic Fitting Tightening Procedure

--------------

Model Specification: Clark TMX12, TMX13, TMX15s, TMX15, TMX17, TMX18, TMX20, TMX20x, TMX25 Forklift Trucks
Total Pages: 427
File Format: PDF
Requirements: Adobe PDF Reader
Language: English
Compatible: All Versions of Windows & Mac, APP ISO, Iphone, Ipad, Android etc...

--------------
