Linde Reach Truck Type116-03:R14X-03-R17XHD-03 Manual

Illustrated Factory Service Training (Workshop) Manual for Linde Electric Reach Truck Type 116-03.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
R14X-03
R16X-03
R17X-03
R17XHD-03

Format: PDF, 336 Pages
Language: English

Contents:

0. Product information
Safety
Maintenance safety guidelines
Service
Covers and cowlings
Emergency lower
Emergency steering and parking brake release
Securing for transportation
Slinging the truck
Towing procedure
Jacking the truck
Mast unit
Service plans - standard
50 h Service plan
1000 h Service plan
2000 h Service plan
5000 h Service plan
10000 h Service plan
Service plans - cold store
50 h Service plan (cold store)
250 h Service plan (cold store 250 h to 6500 h)
250 h Service plan (cold store 6750 h to 13250 h)
250 h Service plan (cold store 13500 h to 19750 h)
1000 h Service plan (cold store)
2500 h Service plan (cold store)
5000 h Service plan (cold store)
Recommended lubricants
Special tools, sealants and compounds
Standard torques
Non standard torques
Diagnostics
Overview
Canbox
Software update for Canbox
Pathfinder
Traction diagnostic codes
Hydraulic diagnostic codes
Steering diagnostic codes -GEN1up to serial number H2X116C00004
Steering diagnostic codes -GEN2from serial number H2X116C00005
Display diagnostic codes
LAC22TP diagnostic codes
3. Chassis, bodywork and fittings
Covers and panels
Covers and panelling
Operators step
Operators seat
Seat
Seat and support plate assembly
Console and storage receptacle
Storage receptacle
Operators console
4. Undercarriage
Electrical steering - (GEN 1 up to serial number H2X11 6C00004)
Steering wheel and column
Steering wheel potentiometer
Drive wheel position potentiometer
Electrical steering - (GEN 2 from serial number H2X11 6C00005)
Steering wheel and column
Steering wheel sensor
Drive wheel position sensor
Wheels and tyres
Drive wheel
Load wheel
Brake installation
Load wheel brake
Master cylinder
Bleeding the brakes
5. Controls
Operating elements
Direction switch
Right-hand armrest
6. Electric/electronic
Battery and accessories
Battery
Changing the battery using changing station
Battery changing interlocks
Electrical control
Safety precautions
AC Control - operating principle
Connector locations
Control unit
Fuses
Emergency isolator
13 Volt power supply -U1
Control module (LDC 61)-A2
Connector X13
Power module (LAC 22) - A1
Charge resistor module - A11
Height encoder and reference sensor
Electrical control -Traction
Traction enable signal
Direction selection switch
Parking brake
Accelerator
Traction motor speed sensor
Brake pedal switch
Regenerative braking
Traction motor temperature sensor
Height controlled speed reduction
Curve control
Electrical control - Hydraulics
Hydraulic enable signal
Valve voltage supply
Joysticks
Joystick voltage supply
Joystick operation
Hydraulic pump motor speed sensor
Hydraulic pump motor temperature sensor
Lower lock valve
Primary lift slowdown sensor
Lower slowdown and stop sensors
Lift and lower - electrical operation
Reach - electrical operation
Sideshift - electrical operation
Manual tilt - electrical operation
Electrical control - steering (GEN 1 up to serial number
H2X116C00004)
Steering system overview
Drive wheel position potentiometer
Steering wheel unit
Electrical control - steering (GEN 2 from serial number
H2X116C00005)
Steering system overview
Drive wheel position sensor (3R1 2)
Steering wheel unit (3R11 )
Electrical control - Display
Operators display
7. Hydraulic installation
Operating hydraulics
Hydraulic functions overview
Hose cassette
Hydraulic motor and pump assembly
Joysticks
Valve blocks
Chassis valve block
Carriage valve block
8. Load lift system
Mast unit
Mast
Mast retainers
Mast operation troubleshooting
Cylinders
Secondary lift cylinder
Reach cylinder
Sideshift cylinder
Load support
Forks
Fork carriage
Reach carriage

Annex
10. Circuit diagrams
Electric diagrams (GEN 1 Steering up to serial number H2X116C00004)
Circuit Diagram (1 of 4)
Circuit Diagram (2 of 4)
Circuit Diagram (3 of 4)
Circuit Diagram (4 of 4)
Circuit diagram -keycode
Circuit Diagram- Options (1 of 4)
Circuit Diagram -Options (2 of 4)
Circuit Diagram -Options (3 of 4)
Circuit Diagram -Options (4 of 4)
Circuit diagram (Options) - keycode
Circuit Diagram -Attachment carriage (1 of 4)
Circuit Diagram -Attachment carriage (2 of 4)
Circuit Diagram -Attachment carriage (3 of 4)
Circuit Diagram -Attachment carriage (4 of 4)
Circuit diagram (attachment carriage) - keycode
Circuit diagram -cold store cabin (1 of 4)
Circuit diagram -cold store cabin (2 of 4)
Circuit diagram -cold store cabin (3 of 4)
Circuit diagram -cold store cabin (4 of 4)
Circuit diagram (cold store cabin) -keycode
Cold store cabin
Cold store heaters
Lighting circuit
Lighting circuit - keycode
Electric diagrams (GEN 2 Steering from serial number H2X116C00005)
Circuit diagram -GEN2 steering (Standard) 116 802 60 51
Circuit diagram -GEN2 steering (Options) 116 802 60 52
Circuit diagram -GEN2 steering (Cold Store Cabin) 116 802 60 53
Circuit diagram- GEN2 steering (Attachment Carriage) 116 802 60 54
Hydraulic diagrams
Hydraulic circuit
