METRIX SWEEP GENERATOR WX 601B Instruction manual
Instruction manual
IM 458
IC 3.2026
EB/pb
Edition September 1969
(service manual)
English language, 52 pages
Seamless scans
text 150dpi, images/ schmeatics 300dpi grayscale lossless LZW tiff scans, lossless ZIP PDF compression, 15 MBytes
Retouched and normalized, print ready.
Table of Contents:
Repair 1
Contents 2
-I- GENERAL 3
1.1. Purpose 3
1.2. Description 3
-II- SPECIFICATIONS 5
2.1. WX 601B Sweep generator 5
2.2. W3 601A Oscilloscope 6
2.3. Accessories 8
-III- SWITCHING ON 10
3.1. Control lay-out 10
3.1.1. Sweep generator - Front panel 10
3.1.2. Sweep generator - Rear panel 13
3.1.3. Oscilloscope model W3 601A 14
3.2. Instructions for use 15
3.2.1. Miscellaneous 15
3.2.2. Preliminaries 17
3.2.3. Response curve display 17
3.2.4. Marking the curve 19
3.2.4.1. External markers 19
3.2.4.2. 10 MHz marker pips and multiples 20
3.2.4.3. 10 + 1 MHz markers 20
3.2.4.4. V + 1 MHz marker pips 20
3.2.4.5. Video and sound marker pips 20
3.2.5. IP Video curve modulation 21
3.2.5.1. Connection 21
3.2.5.2. Working instructions 22
3.2.5.3. Marking 22
3.2.5.4. Interpreting the IF video curve 22
3.2.6. Plotting an IF sound curve 23
3.2.6.1. Connection 23
3.2.6.2. Working instructions 24
3.2.6.3. Marking 24
3.2.6.4. Interpreting the curve 24
3.2.7. Plotting drum tuned plug-in curve 25
3.2.7.1. Connection 25
3.2.7.2. Working instructions 26
3.2.7.3. Marking 26
3.2.7.4. Interpreting the curve 26
3.2.8. Plotting whole curve of a UHF tuner 26
3.2.8.1. Connection 26
3.2.8.2. Working instructions 27
3.2.8.3. Marking 28
3.2.8.4. Interpreting the curve 28
3.2.9. Use of the AM RF sound carrier 28
3.2.9.1. Connection 28
3.2.9.2. Working instructions 29
3.2.9.2.1. Prelimineries 29
3.2.10. Displaying the IP and discriminator
curve of a FM receiver 30
3.2.10.1. Working instructions 30
3.2.10.2. Marking 30
3.2.10.3. Interpreting the curve 31
3.2.11. Using the sweep generator coupled
with an oscilloscope 31
3.2.11.1. Connection 31
3.2.12. Using the curve amplifier 32
3.2.12.1. Connection 32
3.2.12.2. Working instructions 32
3.2.13. To use the 20 Volt power supply 32
3.2.14. Pitting a new coil strip into
the drum tuned plug-in 32
3.3. Coil strips calibration 32
3.3.1. Two types of coil strips are in use 32
3.3.2. Procedure to be followed 33
3.4. Assembling the oscilloscope W3 601A
to the sweep generator WA 601B 34
3.4.1. Dismantling 34
3.4.2. Mounting 34
3.5. Mounting the coupled instruments
into a rack 35
INSTRUMENT DESIGN 36
4.1. Basic design 36
4.2. RF Wobbulated signal generator 37
4.2.1. Linearizing 38
4.2.2. Square signal generator 38
4.3. Frequency marker generator 38
4.4. Marker mixer 39
4.4.1. Marker amplifier - Curve amplifier
and clamping 39
4.5. 1 KHz Oscillator 39
4.6. Stabilised power supply 39
4.7. Wl 601A plug-in 40
4.8. W2 601A IF plug-in 40
4.9. Oscilloscope W3 601A 40
4.10. Vertical amplifier 41
4.11. Horizontal amplifer 41
4.12. Power supply 41
SCHEMATICS
FIG.1 Front view IC 3.2041
F1G.2 Rear view of the sweep generator IC 3.2042
FIG.3 Osoilloscope front view IC 3.2043
PIG.4 Block diagram
FIG.5 Schematic diagram
FIG.6 Schematic diagram (OSCILLOSCOPE)
F10.7 Schematic Diagram (PLUG-IN UNITS)
